Grande has a cost-effective, portable solution for the complete prefabricated camp site works to set up, to assist clients such as rescue operations, and non-governmental organizations, and other customers who require a prefabricated, relocatable building for use in remote locations.
Folding Container Parameters
| Supporting equipment: | Parameters: |
| Wall: Thermal insulation rock wool color steel composite sandwich panel. | Roof bearing: 50 Kg/m² Floor bearing capacity: 150 kg/m² |
| Floor: Adopt A-glass Fire-proof board. | Walkway bearing capacity: 200 kg/m². Wall side pressure: 80 kg/ m². |
| Windows: The window adopts push-pull series made of aluminum alloy for anti-theft. | Wall deformation coefficient: 300 kg/ m² |
| Security door: Anti-theft Steel door is to be used. | Fire resistance rating: Grade A fire resistance, |
| Electrical system: circuit protector, five-hole socket, LED lamp, air conditioning socket, light switch. | Anti Earthquake: 10 Grade. |
| Top: 104 type color steel tile is used for the outer top, and 831 type ceiling tile is used for the inner top. | Anti- wind resistance rating: 11 wind resistance rating |
| | |
Product Details
| Classification | Heading | Specification |
| Size | Length | 5800mm |
| | Width | 2500mm |
| | Height | 2450mm |
| Steel Structure | Pillar | Galvanized pipe |
| | Beams | Galvanized pipe |
| Board | Roof | 14.5㎡ thermal insulation rock wool |
| | Wall | 50mm thermal insulation rock wool color steel plate |
| | Ground | 15mm A-class fire-resistant cloth board |
| Accessories | Window | 950mm*1200mm aluminum alloy anti-theft integrated |
| | Door | 860mm*1980mm special anti-theft door for folding box |
| Paint | Integral frame protective coating | Carpoly High Gloss Enamel |
Characteristical
- Anti-theft Steel door is to be used. Composite sandwich panel which can reach A-class fire prevention.
- The post-holding height is only 44CM.
- The roof is also covered with grade a fireproof rock wool.
Advatage
Safe Using
The installation is convenient and fast. The front and rear door are designed to be pulled up. Engineer will be outside when the house be installed. The safety factor reaches the highest index. It can be very convenient for installation and save time and labor.
Technical Details
Customized concave-convex galvanized heterosexual rectangular tube frame
The entire frame profile of the folding box is formed at one time by large-scale high-frequency welding equipment. All its joints are designed with concave and convex bites, which have excellent sealing performance and are windproof, leakproof and rainproof. The concave and convex design is seamlessly spliced, The fuselage does not need glue bonding, the sealing performance is strong, and it can be folded and used repeatedly.
FAQ
Q. What is your payment term?
A. Our payment term : for standard products 30% deposite, the banlance should be paid before delivery.
( for Customized products,will depend on the design. )
Q. What's the application?
A. the container can be used to container office, container house,prefabricated house, hotel, clinic, dormitory, camp,toilet,bathroom, bedroom, canteen, shop, shower room, storage room, hospital and so on.
Q: How much is the price of the folding container? Is there a discount for bulk purchase?
A: Please contact us for specific information, we will have someone to answer:
Mailbox: foldingcontainerhome@outlook.com
